Cast Resin Transformers

Product Description

Cast Resin Transformers are dry-type transformers where the windings are fully encapsulated in epoxy resin under vacuum conditions. This encapsulation offers robust protection against moisture, dust, and corrosive environments, ensuring reliable operation even in humid conditions. The absence of oil eliminates fire hazards, making them suitable for both indoor and outdoor installations. Tirupati Transformers+9T Power Transformer+9Intact Controls+9

Advantages of Cast Resin Transformers:

• Safety: Their non-flammable design significantly reduces fire risks.

• Environmental Friendliness: Being oil-free, they pose no risk of leaks, ensuring safe and clean operation.

• Durability: The epoxy resin encapsulation provides excellent protection against adverse ambient conditions, including high humidity.

• Low Maintenance: Their sealed insulation system requires minimal upkeep, reducing downtime and operational costs.

• Versatility: Suitable for various applications, including industrial plants, commercial buildings, and renewable energy systems.

Technical Specifications:

• Power Capacity: Available from 125 kVA to 2,500 kVA.

• Voltage Class: Up to 33 kV.

• Frequency: 50 Hz.

• Insulation Class: F or H, with temperature rises of 155C and 180C above ambient temperature (50C), respectively.

• Cooling Methods: Air Natural (AN) and Air Forced (AF).
